Electro‑Galvanized (EG) Steel Plate is produced through an electrolytic zinc‑coating process, resulting in:
A uniform, thin zinc layer
A smooth, bright, defect‑free surface
Excellent paintability and formability
Precise thickness control
Superior surface quality compared to HDG
EG steel plate is widely used in automotive manufacturing, home appliances, electronics, and precision‑formed industrial components where surface quality is critical.
🟪 Product Specifications
Thickness: 0.3 – 2.0 mm
Width: 600 – 1500 mm
Length: Custom lengths available
Zinc Coating (EG):
ZE30 / ZE50 / ZE75 / ZE100 / ZE120
Standards:
ASTM A879
JIS G3313
EN 10152
Surface Types:
Smooth Surface
Skin‑Passed
Surface Treatment:
Chromated
Oiled
Dry
Anti‑fingerprint
🟪 Key Features
Ultra‑smooth surface finish
Uniform and precise zinc coating
Excellent paint adhesion
Good formability and weldability
Ideal for automotive and appliance applications
Better surface quality than HDG
🟪 Included Grades
Commercial Grades
SECC / SECD
DC51D
Automotive / Appliance Grades
SECE / SECF
🟪 Mechanical Properties (Typical)
Grade
Yield Strength
Tensile Strength
Elongation
Notes
SECC
≥140 MPa
270–410 MPa
≥28%
Standard EG steel
DC51D
≥140 MPa
270–500 MPa
≥22%
General forming grade
🟪 Chemical Composition (Typical)
Grade
C (%)
Mn (%)
Si (%)
P (%)
S (%)
Notes
SECC
≤0.12
≤0.60
≤0.50
≤0.10
≤0.045
Appliance grade
DC51D
≤0.12
≤0.60
≤0.50
≤0.10
≤0.045
General EG steel
🟪 Physical Properties (General)
Density: 7.85 g/cm³
Surface Smoothness: Very high
Corrosion Resistance: Moderate (lower than HDG, higher than cold‑rolled)
Paintability: Excellent
Zinc Adhesion: Excellent
🟪 Applications
Automotive body parts
Home appliances (refrigerators, washing machines, microwaves)
Electronic components
HVAC systems
Office equipment
Electrical cabinets
Precision‑formed industrial parts
🟪 Why Use It
Electro‑galvanized steel plate offers a smooth, uniform, and highly paintable surface, making it ideal for automotive, appliance, and electronic applications where appearance and precision are critical. Its controlled zinc layer ensures excellent adhesion, formability, and surface consistency.
