ASTM A515 Pressure Vessel Steel Coil | Boiler & Pressure Vessel Steel | Grade 60/65/70

🟧 Product Overview

ASTM A515 is a carbon–silicon pressure vessel steel grade intended for intermediate and higher temperature service. It is commonly used in welded boilers, pressure vessels, and heat exchangers operating at elevated temperatures where good strength and stable performance are required.

A515 is available in Grades 60, 65, and 70, with Grade 70 being the most widely used. Compared with A516, A515 is optimized more for higher temperature service and less for low‑temperature notch toughness.

🟧 Standards

• ASTM A515 – Pressure Vessel Plates, Carbon Steel, for Intermediate‑ and Higher‑Temperature Service
• Related Standards: ASTM A516, ASTM A537, ASTM A387, EN 10028, JIS G3103, GB Q345R/Q370R

🟧 International Pressure Vessel Steel Standards Comparison Table

Country	Standard	Common Grades
China	GB 713 / GB 19189	Q245R, Q345R, Q370R
America	ASTM A516 / A515 / A537 / A387 / A203 / A204 / A285 / A202	A516 Gr60/70, A515, A537, A387, A203, A204, A285, A202
Germany	DIN 17155	HII, 19Mn6
Japan	JIS G3103	P235GH, P265GH, P295GH, P355GH
France	NF A 36‑205	A42CP, A48CP
Britain	BS 1501	161‑430A/B
International (EN)	EN 10028	P235GH, P265GH, P355GH

🟧 Available Grades

• ASTM A515 Grade 60
• ASTM A515 Grade 65
• ASTM A515 Grade 70

🟧 Product Specifications & Available Sizes

Dimensions

• Thickness: 3 – 20 mm
• Width: 1000 – 2000 mm
• Coil ID: 508 mm / 610 mm
• Coil OD: 900 – 2000 mm
• Coil Weight: 3 – 15 MT

Regular Sizes (mm)

Size	Size
3.0 × 1500 × C	5.75 × 1800 × C
3.5 × 1500 × C	5.75 × 2000 × C
3.75 × 1500 × C	7.75 × 2000 × C
4.5 × 1500 × C	7.5–11.75 × 1500 × C

🟧 Chemical Composition (ASTM A515 Grade 70 – typical)

Element	Max (%)
C	0.31
Mn	0.60–1.00
P	0.035
S	0.035
Si	0.15–0.40

🟧 Mechanical Properties (ASTM A515 Grade 70 – typical)

Property	Value
Yield Strength	≥ 260 MPa
Tensile Strength	485–620 MPa
Elongation	≥ 17%

🟧 Physical Properties

• Density: 7.85 g/cm³
• Modulus of elasticity: 200 GPa
• Thermal expansion: 12×10⁻⁶ /K

🟧 Manufacturing Processes

• Hot rolling
• Normalizing (when specified)
• Pickling
• Leveling
• Slitting / Cutting to length
• Surface oiling

🟧 Primary Industry Usage

• Boilers and pressure vessels
• Heat exchangers
• Refinery and petrochemical equipment
• Industrial pressure systems
• Higher‑temperature welded pressure components

🟧 Why Use ASTM A515 Pressure Vessel Steel Coil

• Designed for intermediate and higher temperature service
• Good weldability and forming performance
• Reliable strength for pressure vessel applications
• Available in multiple strength levels (Gr60/65/70)

🟧 Why Choose WelSteels

• Complete range of boiler & pressure vessel steel coils
• Consistent dimensional accuracy and surface quality
• Custom coil cutting and slitting services
• Third‑party inspection (SGS / BV) available
• Export‑grade seaworthy packaging and reliable delivery
